M/B Form Factor
Mini-ITX
Drive bays
1 x 3.5" HDD OR1 x 2.5" SSD OR1 x 120mm Front Fan
Max CPU cooler height
Up to 172 mm (can accommodate giant dual-tower air coolers like the Assassin IV)
Max VGA card length
Up to 305 mm (supports standard 3-slot dual-fan cards directly plugged into the motherboard)
Cooling System
Front: 1 x 120 mm fan (only if you do not install a 2.5" or 3.5" storage drive here).Top: 2 x 120 mm fans.Rear: 1 x 120 mm fan
Material of Chassis
SPCC Steel: Main structural frame and internal brackets.ABS Plastic: Accents and select frame panel pieces.Tempered Glass: Clean left side panel to display the components. (Note: The CH160 Mesh edition swaps this for an ABS/PVC mesh panel)
I/O panel
: 2 x USB 3.0, 1 x USB 3.2 Gen 2 Type-C, and a hybrid Audio Jack
Product Size
200 x 336 x 283.5 mm (Width x Depth x Height, excluding handle)
NW
3.3 kg (The bare case itself)
GW
~4.1 kg (Estimated weight in retail box with high-density protective foam cushions)
PSU Support
SFX, SFX-L, or standard ATX (up to 140 mm long)
