M/B Form Factor
Micro-ATX (M-ATX) / Mini-ITX
Drive bays
Option A: 2 x 3.5" HDD + 1 x 2.5" SSDOption B: 1 x 3.5" HDD + 2 x 2.5" SSD5.25" ODD Bays: None (No support for legacy external optical CD/DVD drives)
Max CPU cooler height
Up to 180 mm (Highly spacious, easily houses large dual-tower air coolers)
Max VGA card length
Up to 340 mm (Accommodates modern triple-fan graphics cards)
Cooling System
: Includes 3 x 120mm RGB static fans out of the box from most official local retail bundles.(Supports up to 7 x 120mm fans total for immersive cooling):Top: 2 x 120 mm fans.Side/Motherboard Tray: 2 x 120 mm fans (best paired with reverse-blade intakes).Bottom (PSU Shroud): 2 x 120 mm fans.Rear: 1 x 120 mm fan. Liquid Cooling Radiator Support:Top: 120 / 240 / 280 mm liquid AIO water-cooling systems.Rear: 120 mm radiator loops.
Material of Chassis
0.5mm SPCC Steel Body + Tempered Glass Front Panel + Tempered Glass Left Side Panel
I/O panel
1 x USB 3.0, 1 x USB 1.0 (or 2.0 depending on batch), HD Audio Jack
Product Size
355 × 225 × 413 mm
Packing Size
(LxWxH): 412 × 281 × 460 mm (Bare case dimensions layout spans 355 x 225 x 413 mm)
NW
~4.20 kg (Standalone chassis structural weight built on 0.5mm steel framing)
GW
~5.25 kg (Total estimated weight packaged inside its retail box)
