M/B Form Factor
Micro-ATX (M-ATX) / Mini-ITX
Drive bays
Option A: 2 x 3.5" HDD + 2 x 2.5" SSDOption B: 1 x 3.5" HDD + 3 x 2.5" SSD
Max CPU cooler height
Up to 160 mm
Max VGA card length
Up to 310 mm (revisions note up to 320 mm without front obstruction)
Cooling System
Includes the front panel ambient RGB cycle illumination strip. (Supports up to 6 fans total for excellent directional thermals):Front: 3 x 120 mm or 2 x 140 mm fans.Top: 2 x 120 mm fans.Rear: 1 x 120 mm fan.
Material of Chassis
0.5mm SPCC Steel Structure + ABS Plastic + Iron Front Mesh + Tempered Glass Side Window
I/O panel
1 x USB 3.0, 2 x USB 2.0, 1 x Microphone Jack, 1 x Headset Jack, Power Button, Reset Button, Dedicated LED Button
Product Size
362 × 200 × 392 mm (Alternative structural logs read 362 x 200 x 395 mm)
Packing Size
(LxWxH): 426 x 244 x 415 mm
NW
4.20 kg
GW
5.00 kg
