M/B Form Factor
ATX / Micro-ATX (M-ATX) / Mini-ITX
Drive bays
1 x 3.5" HDD3 x 2.5" SSD
Max CPU cooler height
Up to 155 mm
Max VGA card length
Up to 310 mm (31 cm)
Cooling System
: Includes 2 x 140 mm (14 cm) RGB static lighting fans pre-mounted at the front panel out of the box. (Supports up to 5 fans total for targeted thermal control):Front: 2 x 140 mm fans (Pre-installed)Top: 2 x 120 mm fansRear: 1 x 120 mm fan . : Due to the shallow 330mm case depth, top-mounted multi-fan liquid loops can clash with high-profile RAM modules. It is highly recommended to use low-to-mid profile CPU air coolers or a standard 120mm rear radiator loop
Material of Chassis
0.4mm SPCC Steel Chassis + ABS Plastic Front Mesh + Tempered Glass Side Panel
I/O panel
1 x USB 3.0, 2 x USB 2.0, HD Audio, 3.5mm Microphone Jack, Power & Reset Buttons
Product Size
330 × 200 × 400 mm (Select alternative framework sheets note 330 x 200 x 440 mm)
Packing Size
330 x 200 x 400 mm
NW
~3.50 kg (Chassis built with a light entry-grade 0.4mm steel structure and single glass pane)
GW
~4.50 kg (Total estimated weight packaged inside its retail shipping box)
