M/B Form Factor
ATX / Micro-ATX (M-ATX) / Mini-ITX
Drive bays
3.5" HDD Bays: 2 internal bays2.5" SSD Bays: 3 internal bays
Max CPU cooler height
Up to 165 mm
Max VGA card length
Up to 360 mm
Cooling System
Includes 4 x 120mm ARGB cooling fans out of the box (3 x front intake fans, 1 x rear exhaust fan). (Supports up to 6 fans total):Front: 3 x 120 mm fans (Pre-installed) or 2 x 140 mm fans.Top: 2 x 120 mm fans (Optional).Rear: 1 x 120 mm fan (Pre-installed). Liquid Cooling Radiator Support:Front: 120 / 240 / 280 / 360 mm liquid AIO water-cooling radiator loops.Top: 120 / 240 mm liquid AIO radiator kits
Material of Chassis
SPCC Steel Framework + ABS Plastic Front Panel + Tempered Glass Left Side Panel
I/O panel
1 x USB 3.0, 2 x USB 2.0, 1 x HD Audio, 1 x Microphone Jack
Product Size
410 × 210 × 450 mm
Packing Size
(LxWxH): 507 x 263 x 466 mm
NW
~4.80 kg (Estimated standalone chassis structural weight for this build class)
GW
~5.80 kg (Total weight when packed inside the retail box; shipping logistics and marketplaces calculate a volumetric weight around 13.5 kg to 14.0 kg)
