M/B Form Factor
Standard ATX / Micro-ATX (M-ATX) / Mini-ITX (Fully supports rear-plugging BTF mainboards)
Drive bays
1 x 3.5" HDD Bay2 x 2.5" SSD Bays
Max CPU cooler height
Up to 175 mm
Max VGA card length
Up to 400 mm (Easily houses flagship massive graphics cards)
Cooling System
(Supports up to 10 x 120mm fans total for comprehensive thermals):Top: 3 x 120 mm fans (Optional).Side/Motherboard Plate: 3 x 120 mm fans (Optional; best paired with reverse-blade intakes).Bottom: 3 x 120 mm fans (Optional).Rear: 1 x 120 mm fan (Optional). Liquid Cooling Radiator Support:Top: 120 / 240 / 360 mm liquid AIO water-cooling systems.Rear: 120 mm radiator loops
Material of Chassis
Premium 0.8mm SPCC Steel Body + Dual Tempered Glass Panels
I/O panel
1 x USB 3.0, 1 x USB 2.0, 1 x HD Audio, 1 x Microphone Jack, Power & Reset Buttons
Product Size
420 × 285 × 410 mm
Packing Size
(LxWxH): 455 x 345 x 488 mm
NW
~6.80 kg (Chassis built with dual-chamber steel framing and heavy dual tempered glass panes)
GW
~8.00 kg (Total packaged weight inside its retail box; shipping logistics list a dimensional volumetric weight up to 17 kg)
