M/B Form Factor
Micro-ATX (M-ATX) / Mini-ITX
Drive bays
1 x 3.5" HDD Bay2 x 2.5" SSD Bays5.25" ODD Bays: None (No support for legacy external optical drives)
Max CPU cooler height
Up to 160 mm
Max VGA card length
Up to 320 mm (Easily clears most modern dual-fan and compact triple-fan graphics cards)
Cooling System
Includes 3 x 120mm ARGB cooling fans out of the box (2 x reverse-blade fans pre-mounted on the side intake tray and 1 x standard exhaust fan pre-mounted at the rear panel). (Supports up to 7 x 120mm fans total):Side: 2 x 120 mm fans (Pre-installed)Top: 2 x 120 mm fans (Optional)Bottom: 2 x 120 mm fans (Optional floor intake)Rear: 1 x 120 mm fan (Pre-installed),. Liquid Cooling Radiator Support:Top: 120 / 240 mm liquid AIO water-cooling radiator kits (Subject to standard low-profile RAM clearance restrictions due to its compressed vertical height).Rear: 120 mm radiator loops
Material of Chassis
Coated Steel Body Frame + Front Tempered Glass + Left Tempered Glass
I/O panel
1 x USB 3.0, 1 x USB 2.0, 1 x HD Audio Jack, 1 x Microphone Jack
Product Size
325 × 280 × 285 mm
Packing Size
(LxWxH): 395 × 328 × 328 mm
NW
~4.10 kg (Chassis built with dual tempered glass sheets and compact steel framing)
GW
~5.10 kg (Total shipping weight packaged inside its retail box; marketplace couriers calculate a volumetric weight profile around 12 kg due to the box size)
