M/B Form Factor
Micro-ATX (M-ATX) / Mini-ITX
Drive bays
2 x 3.5" HDD Bays1 x 2.5" SSD Bay5.25" ODD Bays: None (No support for legacy external optical drives)
Max CPU cooler height
Up to 157 mm
Max VGA card length
Up to 330 mm
Cooling System
(Supports up to 7 x 120mm fans total for intensive airflow):Top: 2 x 120 mm fans (Optional).Side/Internal Shroud: 2 x 120 mm fans (Optional; best paired with reverse-blade intakes).Bottom (Floor Intake): 2 x 120 mm fans (Optional).Rear: 1 x 120 mm fan (Optional). Liquid Cooling Radiator Support:Top / Side: 120 / 240 mm liquid AIO water-cooling systems.Rear: 120 mm radiator loops
Material of Chassis
Black/White Coated Steel Structure + Dual Tempered Glass Panels
I/O panel
1 x USB 3.0, 1 x USB 2.0, 1 x HD Audio Jack, 1 x Microphone Jack
Product Size
341 × 270 × 375 mm
Packing Size
(LxWxH): 430 × 340 × 425 mm
NW
~4.30 kg (Standalone chassis structural weight with dual tempered glass orientation panels)
GW
~5.30 kg (Total estimated weight packaged inside its retail shipping box)
