M/B Form Factor
ATX / Micro-ATX (M-ATX) / Mini-DTX / Mini-ITX
Drive bays
Option A: 4 x 2.5" SSDOption B: 3 x 2.5" SSD + 1 x 3.5" HDD(Note: Installing a 3.5" hard drive utilizes a shared bay on the chassis floor, which occupies one 120mm bottom fan space)
Max CPU cooler height
Up to 168 mm
Max VGA card length
Up to 355 mm (length can vary based on vertical PSU height positioning)
Cooling System
(Supports up to 6 fans total for chimney-style bottom-to-top airflow):Top: 2 x 120 mm or 2 x 140 mm fans.Bottom: 3 x 120 mm or 2 x 140 mm fans (blows fresh air directly onto the GPU).Rear: 1 x 120 mm fan
Material of Chassis
0.6mm – 0.8mm SPCC Steel + ABS + Dual 3mm Tempered Glass Panels
I/O panel
1 x USB 3.2 Gen 1 Type-C, 1 x USB 3.0, 1 x Hybrid Audio Combo Jack
Product Size
413 × 204 × 398 mm (including front fascia)
Packing Size
(LxWxH): 470 x 275 x 463 mm
NW
5.40 kg (Chassis made of up to 0.8mm SPCC steel structure)
GW
~6.50 kg (Total shipping weight in standard retail packaging)
