M/B Form Factor
Micro-ATX (M-ATX) / Mini-ITX
Drive bays
1 x 3.5" HDD Bay1 x 2.5" SSD Bay5.25" ODD Bays: None (No support for legacy external optical drives)
Max CPU cooler height
Up to 155 mm
Max VGA card length
Up to 280 mm (Limits build options to standard single or dual-fan graphics cards)
Cooling System
Includes 3 x 120mm Fixed RGB fans pre-mounted at the front intake position out of the box to deliver immediate ventilation. Front: 3 x 120 mm fans (Pre-installed).Top: 2 x 120 mm fans (Optional).Rear: 1 x 120 mm fan (Optional). Liquid Cooling Radiator Support: Due to the narrow 195mm frame body width and shallow depth, standard top-mounted dual-fan liquid loops will conflict with RAM modules. It is strongly recommended to stick to standard low-profile CPU air coolers (under 155mm) or a 120mm rear radiator.
Material of Chassis
Coated SPCC Steel Structure + ABS Plastic + Front Mesh Panel + Tempered Glass Side Panel
I/O panel
1 x USB 3.0, 2 x USB 2.0, 1 x HD Audio Jack, 1 x Microphone Jack
Product Size
320 × 195 × 395 mm
Packing Size
(LxWxH): 438 × 243 × 373 mm
NW
~3.30 kg (Estimated standalone chassis structural weight for its entry-level 0.45mm steel layout)
GW
~4.30 kg (Total estimated weight packaged inside its retail box; note that local shipping logistics use a volumetric dimensional profile up to 13 kg)
