M/B Form Factor
Micro-ATX (M-ATX) / Mini-ITX
Drive bays
1 x 3.5" HDD Bay (Shared configuration depending on lower fan mounting layouts)1 x 2.5" SSD Bay5.25" ODD Bays: None (No support for legacy external optical CD/DVD drives)
Max CPU cooler height
Up to 160 mm (Select revisions log up to 165 mm room)
Max VGA card length
Up to 270 mm (Can fit up to 345 mm if side internal space remains open)
Cooling System
Includes 3 x 120mm RGB static cooling fans out of the box from most official local retail bundles. (Supports up to 7 fans total for directional airflow):Top: 2 x 120 mm fans.Right/Side Tray: 2 x 120 mm fans.Bottom: 2 x 120 mm fans.Rear: 1 x 120 mm fan.Liquid Cooling Radiator Support:Top / Side: 120 / 240 mm liquid AIO water-cooling radiator kits.Rear: 120 mm radiator loops.
Material of Chassis
Convex Metal / SPCC Steel Body + Tempered Glass Front Panel + Tempered Glass Side Panel
I/O panel
1 x USB 3.0, 2 x USB 2.0, HD Audio Jack, Power Button, Reset Button
Product Size
350 × 210 × 380 mm (Structure framework measures 370 x 190 x 290 mm)
Packing Size
Carton Dimensions (LxWxH): 428 × 235 × 350 mm
NW
~3.90 kg (Estimated standalone chassis structural weight optimized for entry-level dual-glass builds)
GW
~4.90 kg (Total estimated weight packaged inside its retail shipping carton box)
